Supercross BMX | Vision F1x

The Vision F1x – The Evolution of the World’s First Monocoque BMX Racing Frame

Beyond Best. The New Standard.

The Vision F1 changed the game as the world’s first Monocoque (one-piece) Carbon Fiber BMX Racing Frame. The Vision F1x perfects it.

The Vision F1x is the evolution of the world's first monocoque BMX racing frame. Where the Vision F1 introduced one-piece carbon construction to BMX, the F1x takes the material science to its absolute limit. The carbon layup has been upgraded from T1100-KS to a proprietary blend of Toray M40X and M46X prepreg carbon — the same fiber used by the Red Bull Formula 1 team in their race chassis. The result: lighter than anything Supercross has ever built, stiffer at the bottom bracket and dropouts, and faster off the gate than any frame in the Vision F1 lineup.

Next-Gen Carbon Technology: The "X" Factor

The F1x isn't just an update; it is a material transformation. We have upgraded the monocoque chassis from the previous T1100 KS to a cutting-edge blend of Toray M40X and M46X Carbon Fiber with Nano Alloy Resin.

• Lighter: The superior properties of M-Series carbon allow us to reduce wall thickness without sacrificing structural integrity.

• Stiffer: The high-modulus M40X and M46X fibers provide instant power transfer. When you snap out of the gate, the F1x reacts immediately.

• Stronger: The Nano Alloy Resin prepreg system binds the fibers on a molecular level, creating a chassis that is as durable as it is fast.

Optimized Fork & Chassis Integration

• Frame: Full Monocoque Toray M40X/M46X Blend with Nano Alloy Resin.

• Fork: A specifically tuned blend of Toray fibers reinforced with Nano Alloy Resin to match the stiffness profile of the new F1x frame, ensuring precise handling and unmatched durability.

Versatile Brake & Axle Options

The Vision F1x retains the forward-thinking flexibility you love, ensuring it fits your specific setup:

• Braking: Compatible with V-Brakes or Disc Brakes (removable mounts included).

• Axles: Choice of 10mm or 15mm axles (Pro size and larger feature both options; smaller frames use 10mm only).

Component Standards & Geometry

• Pro Size & Larger: Features a 1 1/8” to 1.5” Integrated Headtube and the T47 Bottom Bracket Standard. This allows for larger bearings and stiff 30mm spindles while keeping the precision and creak-free reliability of a threaded BB shell.

• Expert XL & Smaller: Utilizes a Campy Integrated headset with a traditional 68mm European BB shell to keep weight optimized for younger riders.

What’s Included in Each F1x Kit

• Vision F1x Monocoque Carbon Fiber Frame

• Removeable V-Brake Mounts

• Removable Disk Brake Mounts

(Note: Mini, Junior, Expert & Expert XL Chassis kits contain 1 set of FLIP/CHIPs for the 10mm axle size and utilize a 10mm front dropout).

Please note, Forks, Disc adapters, Headsets, are all sold separately per the links on this page.
